Structure:

Aluminum Conductor Steel Reinforced

Application:

It is widely used in high voltage or ultra high voltage power transmission and transformation lines with a large span

Code Name

Cross Section

Stranding Design Aluminum / Steel

Diameter of Aluminum Wires

Diameter of Steel Wire

Nominal O.D. of Conductor

Nominal Weight

Rated Strength

Maximum DC Resistance at 20℃

mm2

mm

mm

mm

kg/km

kN

Ω/km

Robin

49.47

6/1

3.00

3.00

8.99

171.1

15.8

0.6743

Sparrow

39.25

6/1

2.67

2.67

8.03

135.7

12.7

0.8499

Swan

24.67

6/1

2.12

2.12

6.35

85.3

8.3

1.3522

Raven

62.46

6/1

3.37

3.37

10.11

216.1

19.5

0.5341

Quail

78.64

6/1

3.78

3.78

11.35

272.0

23.6

0.4242

Pigeon

99.16

6/1

4.25

4.25

12.75

343.0

29.4

0.3364

Penguin

125.10

6/1

4.77

4.77

14.30

432.7

37.1

0.2667

Waxwing

142.59

18/1

3.09

3.09

15.47

430.2

30.7

0.2127

Partridge

157.22

26/7

2.57

2.00

16.31

545.9

50.3

0.2136

Ostrich

176.69

26/7

2.73

2.12

17.27

613.4

56.5

0.1900

Merlin

179.91

18/1

3.47

3.47

17.37

542.8

38.7

0.1686

Linnet

198.03

26/7

2.89

2.25

18.29

687.5

62.7

0.1695

Oriole

210.26

30/7

2.69

2.69

18.82

783.3

77.0

0.1698

Chickadee

212.59

18/1

3.77

3.77

18.87

641.3

44.0

0.1427

Brant

227.54

24/7

3.27

2.18

19.61

761.0

64.9

0.1434

Ibis

234.02

26/7

3.14

2.44

19.89

812.4

72.5

0.1435

Lark

248.38

30/7

2.92

2.92

20.47

925.2

90.3

0.1437

Pelican

255.16

18/1

4.14

4.14

20.68

769.7

52.5

0.1189

Flicker

273.11

24/7

3.58

2.39

21.49

913.5

76.5

0.1194

Hawk

280.86

26/7

3.44

2.67

21.79

975.1

86.7

0.1196

Hen

298.12

30/7

3.20

3.20

22.43

1110.6

105.9

0.1198

Osprey

297.54

18/1

4.47

4.47

22.33

897.7

60.9

0.1019

Parakeet

318.62

24/7

3.87

2.58

23.22

1065.6

88.1

0.1024

Dove

327.92

26/7

3.72

2.89

23.55

1138.6

100.5

0.1024

Peacock

346.45

24/7

4.03

2.69

24.21

1158.9

96.1

0.09416

Squab

356.28

26/7

3.87

3.01

24.54

1237.0

108.1

0.09425

Wood Duck

378.04

30/7

3.61

3.61

25.25

1408.4

128.6

0.09444

Teal

376.40

30/19

3.61

2.16

25.25

1396.6

133.4

0.09444

Kingbird

340.27

18/1

4.78

4.78

23.88

1026.6

69.8

0.08914

Swift

331.14

36/1

3.38

3.38

23.62

956.5

61.4

0.08919

Rook

364.07

24/7

4.14

2.76

24.82

1217.5

100.5

0.08959

Grosbeak

374.71

26/7

3.97

3.09

25.15

1300.8

112.1

0.08961

Scoter

397.45

30/7

3.70

3.70

25.88

1480.7

135.2

0.08982

Egret

395.80

30/19

3.70

2.22

25.88

1469.0

140.1

0.08982

Flamingo

381.72

24/7

4.23

2.82

25.40

1276.6

105.4

0.08545

Gannet

392.67

26/7

4.07

3.16

25.76

1363.3

117.4

0.08551

Stilt

409.70

24/7

4.39

2.92

26.31

1370.4

113.4

0.07961

Starling

421.62

26/7

4.21

3.28

26.70

1463.7

126.3

0.07964

Redwing

444.94

30/19

3.92

2.35

27.46

1650.6

153.9

0.07988

Coot

414.00

36/1

3.77

3.77

26.42

1195.8

74.7

0.07134

Cuckoo

455.01

24/7

4.62

3.08

27.74

1522.2

124.1

0.07169

Drake

468.61

26/7

4.44

3.45

28.14

1626.4

140.1

0.07165

Tern

430.58

45/7

3.38

2.25

27.00

1331.8

98.3

0.07170

Condor

454.79

54/7

3.08

3.08

27.74

1520.7

125.4

0.07172

Mallard

494.79

30/19

4.14

2.48

28.96

1836.0

170.8

0.07185

Ruddy

487.44

45/7

3.59

2.40

28.73

1507.3

108.5

0.06334

Canary

515.16

54/7

3.28

3.28

29.51

1723.1

141.9

0.06332

Catbird

496.90

36/1

4.14

4.14

28.96

1434.4

88.1

0.05944

Rail

516.83

45/7

3.70

2.47

29.59

1598.1

115.2

0.05974

Cardinal

545.93

54/7

3.38

3.38

30.38

1825.9

150.3

0.05975

Tanager

538.01

36/1

4.30

4.30

30.12

1553.5

95.2

0.05489

Ortolan

559.54

45/7

3.85

2.57

30.78

1730.5

123.2

0.05518

Curlew

591.20

54/7

3.51

3.51

31.62

1977.6

162.8

0.05518

Bluejay

603.22

45/7

4.00

2.66

31.98

1866.0

132.6

0.05118

Finch

635.77

54/19

3.65

2.19

32.84

2127.8

173.9

0.05143

Bunting

646.09

45/7

4.14

2.76

33.07

1996.9

142.3

0.04778

Grackle

680.81

54/19

3.77

2.27

33.99

2278.1

186.4

0.04802

Skylark

662.64

36/1

4.78

4.78

33.43

1913.6

117.4

0.04457

Bittern

688.90

45/7

4.27

2.85

34.16

2130.8

151.7

0.04482

Pheasant

726.38

54/19

3.90

2.34

35.10

2431.4

193.9

0.04501

Dipper

732.12

45/7

4.40

2.93

35.20

2263.2

161.0

0.04217

Martin

771.51

54/19

4.02

2.41

36.17

2581.7

206.0

0.04237

Bobolink

775.04

45/7

4.53

3.02

36.25

2397.2

170.4

0.03984

Plover

817.10

54/19

4.14

2.48

37.21

2734.9

218.4

0.04001

Nuthatch

818.16

45/7

4.65

3.10

37.24

2529.6

178.4

0.03773

Parrot

861.79

54/19

4.25

2.55

38.23

2883.7

230.0

0.03793

Lapwing

861.60

45/7

4.78

3.18

38.20

2663.5

187.7

0.03583

Falcon

907.86

54/19

4.36

2.62

39.24

3038.5

242.4

0.03601

Chukar

975.86

84/19

3.70

2.22

40.69

3083.1

226.9

0.03216

Bluebird

1181.26

84/19

4.07

2.44

44.75

3731.9

268.2

0.03656

Kiwi

1145.70

72/7

4.41

2.94

44.07

3423.9

221.5

0.02642

Thrasher

1235.08

76/19

4.43

2.07

45.77

3754.2

252.2

0.02477
